Where is the Battery on a 2014 Jeep Grand Cherokee?
Battery Location in the 2014 Jeep Grand Cherokee
The battery in the 2014 Jeep Grand Cherokee is located under the front passenger seat, rather than in the engine bay. This placement helps with weight distribution, protection from heat, and space efficiency.
How to Access the Battery
1. Move the Front Passenger Seat
- Slide the seat all the way back to expose the floor area.
- Adjust the seat height if needed for better access.
2. Remove the Battery Cover
- The battery is beneath a plastic cover on the floor.
- Lift or unscrew the cover to reveal the battery.
Why is the Battery Under the Seat?
- Protects it from extreme engine heat, extending battery life.
- Improves vehicle weight balance for better handling.
- Creates more space under the hood for other components.
How to Replace the Battery
Tools Needed:
- 10mm socket wrench
- Battery terminal puller (if necessary)
- Replacement battery (Group H7/94R)
Steps to Replace the Battery:
- Turn off the vehicle and remove the key.
- Disconnect the negative (-) terminal first, then the positive (+).
- Loosen the battery hold-down clamp and remove the old battery.
- Install the new battery, securing it with the clamp.
- Reconnect the positive (+) terminal, then the negative (-).
- Replace the battery cover and move the seat back to its normal position.
Battery Specifications for a 2014 Jeep Grand Cherokee
- Group Size: H7 (94R)
- Cold Cranking Amps (CCA): 700+
- Voltage: 12V
Signs Your Battery Needs Replacement
- Slow engine crank or clicking noise when starting.
- Dim headlights and electrical malfunctions.
- Battery warning light on the dashboard.
- Frequent jump-starts or failure to hold a charge.
Final Thoughts
The 2014 Jeep Grand Cherokee’s battery is located under the front passenger seat, accessible by moving the seat back and lifting the floor cover. If you need to jump-start the vehicle, use the designated terminals under the hood rather than directly accessing the battery. Always ensure you use the correct battery type when replacing it.
FAQs
1. Can I jump-start the Jeep without accessing the battery?
Yes! Use the jump-start terminals under the hood, located in the fuse box.
2. What battery does the 2014 Jeep Grand Cherokee use?
It requires a Group H7 (94R) 12V battery with at least 700 CCA.
3. Does the 2014 Grand Cherokee have an auxiliary battery?
Some models have a secondary auxiliary battery for start-stop systems.
4. How long does the battery last?
Most batteries last 3–5 years, depending on usage and climate.
5. Can I replace the battery myself?
Yes, but follow proper safety steps: disconnect the negative terminal first and use the correct battery size.
